AirCam VD-240M

ADD INQUIRY
Overview
Overview
Experience superior surveillance with our 2MP Autofocus 40M IR Bullet POE IP Camera, AirCam VD-240M —a state-of-the-art Smart AI surveillance solution. Achieve crystal-clear image quality with autofocus technology. Benefit from powerful 40-meter infrared night vision, ensuring comprehensive coverage day and night. Enjoy easy installation via Power over Ethernet (PoE) for hassle-free setup and monitoring. Moreover, it is a Smart AI featured camera. Capture essential details effortlessly with this advanced IP camera, ensuring your security needs are met effectively.
IK10-Vandal- proof Dome
IK10-Vandal- proof Dome
VD-240M Vandal-Proof Dome Camera offers superior security in a compact, durable design. With its robust construction, this IP camera withstands tampering and harsh weather conditions, making it ideal for outdoor surveillance. Ensure reliable protection for your premises with this resilient and high-performance dome camera.
Features
  • High-Quality Imaging: Equipped with a 1/2.8" Sony CMOS sensor, delivers Full HD resolution (1920 x 1080) output.
  • The camera boasts 4PCS Array IR Led for an impressive 40M IR distance
  • Complemented by a HD 2.8-12mm motorized lens for flexible focal adjustments.
  • With exceptional sensitivity of just 0.001Lux, it excels in low-light conditions, providing clear visuals.
  • Equipped with Day/Night capabilities, AWB, AGC, BLC, and 2D/3D-DNR, it consistently delivers optimal image quality.
Features
  • 4x Optical Zoom
  • Additional functionalities include D-WDR, Motion Detection, Privacy Mask, and Mirror.
  • It seamlessly integrates with RTSP and Onvif 17.06 and supports both H.265 and H.264 dual-stream media server encoding.
  • Enjoy mobile accessibility through Android/iOS App Support, and benefit from an internal microphone for audio capture.
  • Power it via IEEE802.3af PoE and trust in its 4000V lightning protection and IP66 waterproof housing.
2.8-12 mm Motorized Auto focus lens, 4x Optical Zoom
2.8-12 mm Motorized Auto focus lens, 4x Optical Zoom
The AirCam VD-240M is equipped with a versatile 2.8-12mm motorized autofocus lens. This feature ensures precise focus adjustments, allowing for sharp and clear imagery without manual intervention. Enjoy effortless control over your surveillance, capturing every detail with ease and accuracy. Zoom in onto points of interest with the 4x Optical zoom.
IP Camera Android/IOS App Support App. Search VideoLink
IP Camera Android/IOS App Support App. Search VideoLink
Our IP Camera boasts Android and iOS app support, providing convenient access to your surveillance system.
The user-friendly app, "VideoLink," allows you to effortlessly search and view video feeds. Stay connected and in control, monitoring your property from your mobile device with ease and convenience.
Image Enhancement: D-WDR, Mirror, Rotate, and Defogging functions
Image Enhancement: D-WDR, Mirror, Rotate, and Defogging functions
The AirCam VD-240M takes image enhancement seriously, offering a suite of advanced features. Digital-Wide Dynamic Range (D-WDR) balances exposure, ensuring well-lit scenes in challenging lighting conditions. Additionally, it provides the ability to mirror and rotate images as needed, enhancing flexibility in surveillance placement. Furthermore, the integrated Defogging function improves visibility in misty or foggy environments, ensuring that you get clear, detailed footage regardless of adverse weather conditions. These features collectively enhance the camera's performance and its suitability for various monitoring scenarios.
AirCam VD-240M 20 SMD array IR LEDs with a 40-meter IR distance
AirCam VD-240M 20 SMD array IR LEDs with a 40-meter IR distance
The AirCam VD-240M is equipped with 20 SMD array IR LEDs, delivering powerful infrared illumination. With an impressive 40-meter IR distance, it ensures exceptional night vision capabilities, providing clear and detailed surveillance footage even in complete darkness. Whether it's monitoring large outdoor areas or dimly lit spaces, this camera guarantees reliable 24/7 security coverage, making it a robust choice for various applications.
The Power of 4x Optical Zoom
The Power of 4x Optical Zoom
Experience enhanced surveillance capabilities with a 4x Optical Zoom. This feature allows you to magnify and capture distant objects with exceptional clarity and detail, providing greater flexibility and precision in monitoring. Whether it's for security, wildlife observation, or other applications, optical zoom brings subjects closer without compromising image quality.
Hardware
ModelAirCam VD-240M
Device InterfaceNetwork Interface: PoE 802.3af 1x RJ45 10M/100M
Media: AirCam64, Android, IOS, NVR
Onvif: 17.06 compatible
Standard: HTTP/RTSP/FTP/RTMP/SMTP/DHCP/NTP/NFS
CameraImage Sensor : 1/2.8" SONY IMX307 CMOS
CPU: Mstar MC335
Effective Pixels : 2 Megapixels
Electronic Shutter : Auto, 1/25s ~ 1/100000s
Min. Illumination : 0.001Lux@F1.2(AGC ON), 0Lux IR on
Day/Night : Auto/Color/(B/W)/Timing
WDR : Digital WDR/HDR(>120dB)
White Balance : Auto/Indoor/Outdoor
BLC /HLC : Support
DNR : 2D/3D DNR
Other : Motion Detection, Privacy Mask, Mirror, flip
Mechanical: Waterproof IP66 Housing
EncodeVideo Standard : H.264/H.265/H.265+
Video Resolution :
 - Main Stream: 1080P@30fps , 720P@30fps
 - Sub Stream: D1/VGA/360P@30fps
Video Bitrates : 32Kbps - 5Mbps, VBR/CBR
Audio Standard : G.711-u/G.711-a
OSD Overlay: Title and Time overlay
IR Led: 4 pcs array IR Led
IR Distance: 40 Meters
FOV: 1/2.8 |123° x 101.9° x 53.2° ~ 38° x 33.1° x 18.6° (D x H x V) ±5%, 2.8~12mm
Lens Focal length : 2.8-12 mm Motorized lens
Zoom : 4x Optical Zoom
Motion Detection: Human/Schedule/Detection area/Trigger Recording/Trigger Snapshot/Link Blink/Upload Alarm Centre/Trigger Audio
Multiple LanguageEnglish/Chinese/Russian/Deutsch/Italiano/Türkiye/Polski/Korean/Greek/Arabic/Japanese
APP and Software Control
APP/SoftwareWindows: Web browser, AirCam64
iOS/Android: Download “Videolink” App from APP/Play Store)
*NVR APP iOS/Android: Download “Guard Viewer” App from APP/Play Store,
(can be used when camera has been added to ANVR.)
Power Input
Power InputPower Supply: 12V DC
Power Consumption: ≤8 W
PoE: 802.3af
Environment
Operating Temperature-30°C to +60°C
Operating Humidity10%~90%, non-condensing



Ordering Information

ModelAirCam VD-240M
2MP Autofocus Vandal-proof 40M IR POE Dome IP Camera
Standard Package
Product Sizeφ132x 103.9mm, include. bracket
Package SizeTBD (L) x (W) x (H) cm
Package WeightN.W: KGS
G.W: KGS
Package ContentIP Camera/Network cable/QIG/waterproof connector
Carton Package
Quantity PCS / 1 Carton
Dimensions(L) x (W) x (H) cm
Weight  KGS
QIG
NameDescriptionDownloadDate
AirLive AirCam IP Camera Series QIG
2024/03/20
Spec Sheet
NameDescriptionDownloadDate
AirCam VD-240M Spec Sheet
2024/08/05
CE
NameDescriptionDownloadDate
AirLive AirCam Series IP Camera-CE+RoHS
2024/06/20
SDK
NameDescriptionDownloadDate
AirCam Series HTTP_CGI_API
2024/02/27
Firmware & Software
NameDescriptionDownloadDate
Firmware for BU-240M & VD-240M CGI Fix
Fix error in CGI Snapshot
2024/09/10
Airlive AirCam64 VMS
V1.0.0_20231110
2024/03/28
Airlive AirCam Search Tool
V5.7.6_20231102
2023/12/11
How to adjust the Image settings of the AirLive Aircam IP Cameras
Please click the PDF file.

Download
How to setup Email Alarm using Gmail for AirLive Aircam IP Cameras
Please click the PDF file.

Download
Making Snapshop using CGI command.
When making a snapshop using the CGI command for the VD-240M, only a snapshop can be made from the Substream. If you want to use the CGI command to make a snapshot of both the Main and/or Substream then please switch, to a 6MP camera model, e.g. VD-640MAI.
